The U-Net Packet Filter: An Extension to U- Net over Fast Ethernet

Masters of Engineering Project

August 20, 1996

Jonathan Barber (barber@cs.cornell.edu)
Professor Thorsten von Eicken

Department of Computer Science
Cornell University

1.0 Abstract

U-Net is high-bandwidth, low-latency network communication protocol that can deliver parallel-computing horsepower to a network of PCs. In this case, the PCs are connected via a fast ethernet switch. In its original implementation, computers connected through U-Net communicated through a simple communication scheme. The U-Net Packet Filter acts as an extension to the original implementation, giving U-Net the capability to communicate using open standards.

2.0 Overview

The job of the U-Net Packet Filter (UPF) is to demultiplex in-coming packets to their corresponding U-Net endpoint destinations. It is designed to demultiplex both connection-oriented and connection-less packets, depending on the protocol/field combinations.

In the case of connection-oriented packets, a channel specifies an endpoint- to-endpoint connection (i.e. a connection from one process to another). If process A connects to process B, then A can only communicate with B, and B can only communicate with A on that channel. If A wants to communicate with C, then it must open a separate channel.

In the case of connection-less packets, program A can open a broadcast or multicast channel. Any other process listening on that channel can receive packets sent from A.

3.0 Design Goals

The U-Net Packet Filter was designed with two goals in mind:

  1. Above all, it has to be fast. The ability to communicate over open standards is useless to U-Net if it can do so only at normal network data- rates.

  2. The Packet Filter's topology has to be simplistic, and easily expandable. New filters cannot been written in pseudo-assembly and interpreted. New filters must programmed into the existing system, however, the packet filter's simplistic structure allows for a certain degree of creativity on the part of the programmer, thereby easing the task of the programming itself.

The subsequent sections in this document discuss in detail the different components and structure of the U-Net Packet Filter, with an eye towards demonstrating that the design goals have been met.

4.0 Implementation

The current implementation, as of the date of this document, allows for 4 distinct filter types. They are, Raw U-Net (the simple communication scheme utilized by the original version of U-Net), Raw Ethernet (U-Net purely at the data-link layer), TCP/IP, and UDP/IP.


4.1 Elementary Components

The U-Net Packet Filter is a Directed A-cyclic Graph (DAG). It is made up of two basic components:

  1. The Cell: this is a data-structure that contains twelve 32-bit word entries. This is the Packet's most basic structure. The cell is used for storing channel information (such as a channel's field values, such as port numbers and addresses), and it is used as a pointer to other cells and hash table. Cells can be chained together to form doubly-linked lists. For complete details and usage information on cells in UPF, click here.

  2. The Hash Table: provided with a hashing function, these tables are used to spread out U-Net channels over a range of HASH_SIZE. Each table contains HASH_SIZE pointers to cells. These cells, as already mentioned, can be chained together in a linked-list. The combination of cells and hash-tables creates a hashing data-structure with chaining, which is the way in which hash tables are utilized in the current implementation of UPF.

Figure 1: Elemantary UPF Components

Together, cells and hash tables are connected together to form a directed a- cyclic graph (DAG). When a packet comes in off of the ethernet wire, each protocol in the composite packet header is broken down into fields. These fields are then compared to information stored in the cells. As matches are found, we follow the appropriate path through the DAG.

The next section breaks down the current architecture of the U-Net Packet Filter, and discusses the protocols it currently supports.


4.2 Protocol Hierarchy in the U-Net Packet Filter DAG

The current implementation supports 4 protocols, two of which are open standards. The following protocols are broken down has follows:

  1. Raw U-Net: The modified version of U-Net (devtulip.c) is backwards compatible with the original implementation of U-Net. That is, packets can be demultiplexed to Raw U-Net channels based on the following fields:

    Figure 2: Raw U-Net Ethernet Header

    These types of channels are not part of the UPF system. In the event that a Raw U-Net channel is detected, the UPF system is by-passed, and the packet is demultiplexed based strictly on the U-Net port number. If the ethernet card is running in promiscuous or multicast mode, then only the U-Net Type and U- Net-Port identify an endpoint/channel. These channels are not guaranteed to be unique.


  2. Raw Ethernet: This protocol is similar to the Raw U-Net protocol, in that it is strictly a data-link layer protocol. Packets are demultiplexed to their corresponding endpoint/channel based on the following fields:

    Figure 3: Raw Ethernet Header

    The combination of these two fields uniquely specify an endpoint (unless the Source Addr is an ethernet multicast or broadcast address). The ethernet type can be any 16-bit value, provided that it is not a reserved field (e.g. the IP ethernet type is 0x0800, and is a reserved type).

    In the case where the only open channel's consist of Raw U-Net (not in the DAG) or Raw Ethernet channels, the DAG is merely a linked-list of ETH- TYPE cells (see the Cell Specification Page).

    Figure 4: Raw Ethernet in the UPF DAG

    When a Raw Ethernet Packet is received, fields the ethernet source and raw ethernet type are compared with the corresponding cell values for each element in the linked-list, until a match is found. For the case(s) in which a large number of Raw Ethernet channels are open, performance may be improved by replacing this linked list with a hash table.


  3. TCP/IP (Transmission Control Protocol/Internet Protocol):

    This is a composite point-to-point protocol. The outer protocol is IP, and the inner is TCP. I refer to this as a single filter, as only both protocols together identify an endpoint. In reality, they are separate protocols.

    The combination of the following fields uniquely identifies a TCP/IP endpoint:

    Figure 5: TCP/IP Composite Header

    Notice that fields from three different protocols uniquely identify a channel. This corresponds to a traversal of the packet filter's DAG. UPF is designed to be fast. This means that in the interests of speed, we want to drop a packet from contention as soon as it is realized that the packet will not demultiplex to any endpoint.

    Of the 7 preceding fields, we know that the packet is not IP if the ethernet type field does not match IP (0x0800). As an optimization, the IP ethernet cell is always located at the head of the Ethernet-level linked-list. Since IP demultiplexing is expensive, this results in just a single ethernet-type check.

    At this point, we now know the packet is of type IP. At the next level in the DAG, we check the protocol and the IP version number. If the protocol is un- defined (i.e. is not TCP or UDP, ..., in this case TCP), or if the IP version number does not match the filter's IP version number, the packet is dropped. Again, this results in traversing a linked-list of protocol cells, or as its referred to in the source code, IP_PROTO cells, until a match is or isn't found.

    Figure 6: At the IP Protocol Level in the UPF DAG

    If a match is found, then we descend another level into the DAG. At this point, we drop the packet if the destination port (TCP Protocol), does not exist in the filter. Since there can be as many as 2^16 possible ports, we perform a lookup into a hash table. The hash table itself is connected to the IP_PROTO cell corresponding to the TCP protocol. The hash function is defined within the source code by the function hash_func_port(). Since it is possible for multiple channels to exist on the same combination, it might be necessary traverse a hash-chain of IP_CHANNEL_HASH cells. These cells contain the destionation port number, and pointer to a Channel hash table.

    Figure 7: At the TCP/IP Channel Hash Level in the UPF DAG

    The 3 remaining fields, IP Source addr, IP Destination addr, and TCP source port, uniquely identify a TCP channel. A hash function is then used, defined by the function hash_func_chan() in the source code, to hash into a table connected to the IP_CHANNEL_HASH node. Again, there can be more than one node connected to a single index in the hash table. The hash function is meant to spread out the different channel combinations, so that a chain of IP_CHANNEL nodes will not have to be walked.

    Figure 8: At the TCP/IP Channel Level in the UPF DAG

    If a match is found in the IP_CHANNEL linked list, we demultiplex the packet to the corresponding endpoint.

    In summary, demultiplexing TCP/IP packets requires traversing the DAG through 3 protocols. Note that the current implementation does not support IP fragmentation. This would be a natural extension to TCP/IP, as well as UDP/IP.


  4. UDP/IP (User Datagram Protocol):

    Traversal of the DAG for UDP/IP is nearly identical to that of TCP/IP. The difference between the two protocols is that UDP/IP can be connection-less, while TCP/IP is always connection-oriented. This means that its possible to establish not only unicast channels, but multicast and broadcast channels as well.

    Traversal of the DAG for UDP/IP requires the same seven fields that were used in TCP/IP. The difference is that at channel setup time, a unicast, multicast, or broadcast channel type can be selected. If the user creates a unicast channel, then traversal of the DAG occurs exactly as it did for TCP/IP, except that the transmission protocol is now UDP.

    Choosing to open a multicast channel results in creating a new level of the DAG. Graph traversal proceeds as it did for TCP/IP, all the way to the IP_CHANNEL node. In UDP, the IP_CHANNEL node contains an x_cast field, which is set to either UNICAST, MCAST, or BCAST. If the field is MCAST, then we descend a level to a linked list of IP_MCAST cells.

    Figure 9: At the UDP/IP Mulitcast Level in the UPF DAG

    Each node in this linked list corresponding to an IP_CHANNEL with the same address information, but with pointers to different channels. In the event that a multicast IP_CHANNEL is matched, then we walk the entire IP_MCAST linked list, and demultiplex at each IP_MCAST cell.

    If the IP_CHANNEL node is of type BCAST, then we must demultiplex to every active channel on this port (dest_port). This results in a traversal of every hash-chain for every index in the hash table connected to the IP_CHANNEL_HASH node. The packet is then demultiplexed to every unicast and multicast channel open on the port. If another broadcast channel is encountered, it is ignored (since a broadcast is already taking place).

    Multicast channels result in demultiplexing to many channels. This involves copying the entire packet into multiple regions of user memory, for as many multicast channels that are open. Broadcast channels result in even poorer performance, since the packet must be demultiplexed to every open channel on the port.

    In general, multicast and broadcast channels may be useful, but they incur a severe performance overhead.


    4.3 Wild-Card Channels in IP

    Both TCP/IP and UDP/IP composite protocols support wild-card channels. In order to demultiplex to an endpoint, the minimal requirements specify that the IP ethernet type, the IP Version number, the transport protocol, and a destination port must be specified. The remaining fields, IP destination address, IP source address, and the source port can remain un-specified (they are declared as a WILD during channel creation). The combination of 3 wild-card fields results in seven distinct wild card priority levels, which are illustrated below.

    Figure 10: IP Channel Hash Table Priority Levels

    The combination of only a WILD IP source address forms the highest priority, while the combination of all WILDS creates the lowest priority.

    Wildcard channels will only pick up packets if there is no matching channel from the next-highest priority level. This functionality is built into hash_func_chan(). Each IP_CHANNEL hash table is partitioned into HASH_ENTRIES - 7 indexed hash buckets. During graph traversal on packet reception, if a packet cannot be demultiplexed via the indexed hash chain, then we traverse each priority level on the corresponding destination port. If a matching wild-card channel is found, UPF demultiplexes on that channel, and graph traversal ends. If not, then UPF continues searching each next lowest priority level until they are all exhausted, at which time the packet can be dropped.

    Note that UDP Multicast and Broadcast channels are implemented as wild-card channels. Since the channels are by definition connection-less, the IP source address and source port fields are WILD. The down-side of this setup is that matching a multicast or broadcast channel requires exactly 3 hash misses (1 for the missed index, and 2 for the preceding wild-card priority levels). If a U-Net parallel program were to rely heavily on IP multicast or broadcast, this scheme may require alteration to boost performance.

    5.0 Using UPF with U-Net, Benchmarks, and Demonstration Programs

    You can obtain a copy of the UPF U-Net source tree, by saving this link. The UPF code is designed to run on a Linux system over Fast Ethernet. However, it should be extremely portable to any U-Net system running over Fast Ethernet. This version, has been tested and bench-marked on Linux 1.3.71 using the U-Net kernel patch ( see the U-Net supporting documentation).

    The source tree contains the following items:

    6.0 Performance Benchmarks

    The U-Net Packet Filter was evaluated using a 133Mhz Pentium and a 90Mhz Pentium, connected to a Fast Ethernet Switch. The programs pingpong_unet, pingpong_eth, and pingpong_ip, were used to test the roundtrip times for sending messages using Raw Unet, Raw Ethernet, and TCP/IP, respectively. 1000 forty-byte packets were sent per test. The following results were taken from several runs.

    Raw-Ethernet performed 4% slower than Raw-Unet. TCP/IP performed 17% slower than Raw-Unet, and 13% slower than Raw-Ethernet.

    Raw-Ethernet's performance was about as expected. Traversal of the DAG is not free, and requires some cycles. TCP/IP's performance is a little disappointing, especially since the channel test was connection-oriented, and was the only channel open during testing. However, the significant performance drain could be partially attributed to the hash lookups implemented with the IP filter. In order to demultiplex to a TCP/IP channel, a packet must traverse through two hash-table lookups. In its current implementation, both hashing functions use a modulo operator. The modulo of the hash function is taken against the number of available hash buckets. The use of the modulo operator incurs a large expense, and might explain a significant portion of TCP/IP's performance drain.

    One way the hash functions can be improved would be to replace the modulo operations with an alternative similar operation, in order to hash a packet into one of the available hash buckets. Rather than use modulo, we could logically and the result of the hash function with a mask corresponding to the log (base 2) of the size of the hash table. This would perform a function similar to the modulo operation while enormously reducing the computational expense of the operation.

    There are undoubtably numerous optimizations one can make to the packet filter to enhance performance. This is left as future work.

    7.0 How to Go About Adding a New Filter to UPF

    Each filter is some combination of cells and hash tables connected together. In meeting the second design goal, the integration of a new filter to UPF is meant to be modular. Each module requires at least 3 routines.

    1. add_Protocol(): a routine to dynamically add a channel of this prototype to the DAG. If the filter has not been installed for this channel type, then the filter is also installed. If the add_Protocol() routine fails, then the channel creation up to the point of the error must be un-done.

    2. find_Protocol(): this routine should be very fast! Its responsible for demultiplexing packets to their endpoints.

    3. deactivate_Protocol(): this routine dynamically removes a channel from the DAG, and de-allocates any memory associated with the channel. If the channel is the last channel of its protocol, then the entire protocol is deactivated. This routine is important for long-running processes, where channels are created and destroyed based on run-time conditions. Its important that all memory be recycled and accounted for. This routine is not as important for short-running programs, such as benchmarks, since the upf_shutdown() routine will de-activate the entire DAG data-structure.

    The current implementation supports 4 different filters: Raw Ethernet, IP, TCP, and UDP. For each segmented protocol, there are exactly 3 essential routines (see the source code). That is, the aforementioned 3 routines exists for every module. Actually, there is only one find_Protocol in the UPF system (upf_findchannel()). However, this routine is broken up into C case statements, essentially breaking down the task of demultiplexing composite headers by protocols.

    The designer of a new filter should feel free to define there own cell types, as is necessitated by the new filter. The designer should feel free to modify the actual cell structure, if will improve the overall packet filter design, and can also define new hash functions as is needed.

    8.0 Memory Management

    All memory allocatation in the UPF system is chained together off of a pointer on the tulip-device structure. As new cells and hash-tables are allocated, a new "wastebucket" structure is added to a garbage collecting list of wastebuckets. Each wastebucket points towards the allocated structure. Each structure in turn points back to the corresponding waste bucket. A call to upf_shutdown() results in a traversal to each wastebucket. At each bucket, the data structure it points to is de-allocated. Since each structure points to its corresponding wastebucket, a call to upf_deactivate() results in proper maintenance of the watebucket linked-list.

    9.0 Other Possible Extensions to UPF

    Througout this document, some possible extensions to UPF have been mentioned. In this section, we will discuss a few more.

    The current implementation of UPF handles multicast and broadcast channels. However, in order to properly join a multicast group, a process needs access to an IP multicast to Ethernet address resolver. The de facto way of doing this now is via IGMP. Therefore, the addition of an IGMP filter to UPF might be a good idea.

    If a group of U-Net processes were to need to dynamically need to create new IP channels, then they would also require a way to resolve straight ethernet to IP address translations. The addition of the Address Resolution Protocol (ARP) filter to UPF would also make a logical extension.

    In general, as many extensions can be made to UPF as is required by the needs of the U-Net user(s)

    10.0 Conclusions

    The attempt to create a packet filter that can be used with U-Net was successful. In doing so, I believe that our original design goals were met. This is, however, a beginning. There is still a lot work that must be done in developing both U-Net, and the U-Net Packet Filter. Particulary in the case of UPF, performance can be improved. Improvements to the current hashing implementation, and tweaks to the source code in general will probably boost overall perforance of the filters.

    11.0 Acknowledgments

    I would like to thank the following individuals for their advice, guidance, and suggestions in designing and developing UPF:
